General

Printer type: Colour Function: Print Display size: 2 Line LCD Laser classification: Class 1 laser product (IEC 60825-1:2007) Memory: 256MB Processor: 800MHz – Sub:133MHz Technology: Laser

Connectivity

Connectivity: Wired Network, Wireless Local interface: Hi-Speed USB 2.0 & USB Host for an external card reader Wired network interface: Ethernet 10Base-T/100Base-TX/1000Base-T Wireless network interface: IEEE 802.11b/g/n

Mobile connectivity

Supported: AirPrint, Android Print Service Plugin, Google Cloud Print 2.0, iPrint&Scan, Mopria, Wi-Fi Direct™

Dimensions & weights

With carton: 617 x 533 x 521mm With carton: 25.4 kg Without carton: 410 x 486 x 313mm Weight: 21.8 kg

Environmental

Blue Angel environmental accreditation: Yes Energy Star environmental accreditation: Yes Nordic Swan environmental accreditation: Yes Sound power: Printing – 6.56BA, quiet mode printing – 6BA, ready – Inaudible Sound pressure: Printing – 49dbA, quiet mode printing – 44dbA, ready – Inaudible Typical electrical consumption: 1.8kWh/Week

In the box

Contents: Power supply cord, Product safety guide, Windows Software disc, Supplies, Warranty card, Quick setup guide

Media specifications

Types and sizes: Standard & Optional Trays – plain, recycled, coloured and letterhead (between 60 - 105g/m2) Multi Purpose Tray - plain, recycled, bond, coloured, letterhead and glossy paper (between 60 -163g/m2) 2-sided Print - plain, recycled, coloured, letterhead and glossy paper (between 60 - 105g/m2) Weights: Standard Tray - A4, Letter, A5, A5(Long Edge), A6, Executive, Legal, Folio, Mexico Legal Multi Purpose Tray- Width: 76.2mm to 215.9mm x Length: 127mm to 355.6mm 2-sided Print – A4

Network

Wi-Fi Direct™: Yes Wired network: Built in Ethernet 10Base-T/100Base-TX Wired network security: SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP), SNMP v3, Kerberos, IPSec, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) Wireless network security: WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP), SNMP v3, Kerberos, IPSec, 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)

Operating systems & software

Supported: Windows 10 (32 & 64 bit editions) Windows 8 (32 & 64 bit editions) Windows 7 (32 & 64 bit editions) Windows Server 2016, 2012, 2012R2 & 2008R2 Windows Server 2008 (32 & 64 bit editions)* *Windows Server supports network printing only Mac: OS v10.10.5, v10.11.x, v10.12 or greater Linux CUPS, LPD/LPRng (x86/x64 environment)

Paper handling

Paper input: Standard Tray - 250 Sheets, Multi Purpose Tray - 50 Sheets Paper output: Face Down - 150 sheets Face Up (Straight Paper Path) - 1 sheets

Printing

Resolution: 2,400 x 600dpi & 600 x 600dpi A4 standard colour print speed: 31 pages per minute A4 standard mono print speed: 31 pages per minute Recommended monthly volume: Up to 3,000 pages

Security features

IP filter: Yes Secure function lock v3: Yes Secure print: Yes Setting lock: Yes

Solutions

Supported: AirPrint, Android Print Service Plugin, b-guard, Box, Brother Apps, BSI, Dropbox, Google Cloud Print, Google Drive, iPrint&Scan, Managed Print Services, Mopria, OneDrive

Supplies and accessories

Accessories: Optional Lower Tray LT-330 - Up to 250 sheets, Supplies: Inbox Toner - Up to.3,000 pages Black, 1,800 pages Cyan, Magenta & Yellow. Standard Toner - Up to 3,000 pages Black, 1,800 pages Cyan, Magenta, & yellow. High Yield Toner - Up to 6,500 pages Black, 4,000 pages Cyan. Magenta & Yellow. Drum Approx. 30,000 pages (1page/job), Approx. 50,000 pages (3page/job) Belt Approx. 50,000 pages (1page/job), Approx. 130,000 pages (3page/job) Waste Toner Box (WT-320CL) Approx 50,000 pages
