| Drive Configuration |
| Device Location: |
Internal |
| Form Factor: |
M.2 22x80mm |
| Storage Capacity: |
250 GB |
| Supports Data Channel: |
PCIe NVMe 4.0 x4 |
| Certifications: |
RoHs |
| Memory Technology: |
3D NAND |
| Flash Memory Cell Technology: |
Triple-Level Cell |
| Included Accessories: |
Quick Start Guide |
| Performance |
| Maximum Random Read Rate: |
210000 IOPS |
| Maximum Random Write Rate: |
280000 IOPS |
| Maximum Sequential Read Rate: |
3200 MB/s |
| Maximum Sequential Write Rate: |
1300 MB/s |
| Total Bytes Written (TBW): |
160 TB |
| Reliability |
| Mean Time Between Failures: |
1800000 hr |
| Solid State Drive Features: |
S.M.A.R.T.
TRIM Support
NVMe Support
Halogen Free |
| Shock Tolerance Operating: |
1500G @ 0.5ms |
| Power Consumption |
| Maximum Power Consumption: |
3 W |
| Environment |
| Maximum Operating Ambient Temperature: |
70 °C |
| Minimum Operating Ambient Temperature: |
0 °C |
| Maximum Non-Operating Ambient Temperature: |
85 °C |
| Minimum Non-Operating Ambient Temperature: |
-40 °C |
| Dimensions & Weight |
| Width (mm): |
22.15 mm |
| Height (mm): |
2.23 mm |
| Depth (mm): |
80.15 mm |
